Hybrid & EV Battery Error Code Guide

Book your FREE diagnostic today

Identify Battery Problems & Get the Right Fix

Hybrid and EV systems can log fault codes when the battery is not performing correctly. These codes help point to common issues like battery pack failure, cooling problems, sensor faults, or high voltage safety concerns so you can choose the right solution.

Hybrid Battery Error Codes, Symptoms, and Troubleshooting Tips

P0A80 – Hybrid Battery Pack Replacement Required

SYMPTOMS:

  • Hybrid system warning light displayed
  • Vehicle may stall, fail to start, or struggle to enter READY mode
  • Reduced performance / slower acceleration

POSSIBLE CAUSES:

  • Battery voltage has dropped below the required operating level
  • One or more battery modules are weak, failing, or out of balance within the pack

P3000 – Battery Control System Malfunction

SYMPTOMS:

  • Engine light and master warning triangle displayed

POSSIBLE CAUSES:

  • High-voltage control system error detected
  • Low fuel supply may contribute to related hybrid system faults
  • HV battery malfunction or abnormal battery ECU readings

P3011–P3027 – Weak Battery Blocks (Toyota Prius 2007–2015)

SYMPTOMS:

  • Reduced MPG / fuel efficiency
  • Poor hybrid battery performance, erratic charge behaviour

POSSIBLE CAUSES:

  • HV battery assembly beginning to fail
  • One or more battery blocks weakening (P3011 = Block 1, P3012 = Block 2, etc.)

    C1241 – Low Battery Positive Voltage

    SYMPTOMS:

    • “Check Engine” or “Service Engine Soon” message
    • ABS warning light may illuminate

    POSSIBLE CAUSES:

    • Low 12V battery charge
    • Weak or failing battery
    • Charging system fault preventing correct battery voltage

    P0AFA – Hybrid Battery System Voltage Low (Toyota)

    SYMPTOMS:

    • Hybrid system warning light
    • Vehicle may stall or refuse to start
    • Reduced power / weaker acceleration

    POSSIBLE CAUSES:

    • HV battery voltage below acceptable range
    • Weak module(s) inside the battery pack creating low pack voltage

    P0A7F – Hybrid Battery Pack Deterioration (Honda Civic & Accord Hybrid 2006–2011)

    SYMPTOMS:

    • Assist/charge gauge behaves abnormally
    • Engine starts more frequently than normal
    • Noticeably worse fuel economy

    POSSIBLE CAUSES:

    • Battery capacity has reduced over time through normal wear
    • Pack cannot hold charge or provide power reliably under load

    P0B47 – Hybrid Battery Voltage Sensor “C” Circuit Low (Toyota)

    SYMPTOMS:

    • Hybrid warning light displayed
    • Vehicle may enter reduced power mode
    • Unusual voltage readings found during diagnostics

    POSSIBLE CAUSES:

    • Voltage sensor failure or wiring problem in “C” circuit
    • Uneven or inconsistent voltage readings across modules

    P0ADC – Hybrid/EV Battery Positive Contactor ‘A’ Control Circuit High (Toyota Camry Hybrid TC1 ONLY)

    SYMPTOMS:

    • Vehicle may stall unexpectedly or fail to start
    • Trouble code stored
    • High-voltage contactor issue indicated

    POSSIBLE CAUSES:

    • Positive contactor relay failure, or contactor stuck open/closed
    • Control circuit or wiring fault preventing proper contactor operation

    P3030 – High Voltage Line Snapped (Toyota Prius)

    SYMPTOMS:

    • Warning light or “Check Hybrid System” message
    • Sudden loss of power
    • Vehicle may not start

    POSSIBLE CAUSES:

    • Broken / open high-voltage wiring
    • Damaged sensing harness, connector, or plug connection
    Load More

    Revitalise Your Hybrid for Less

    Why settle for high main dealer costs? At Greentec Auto, we provide cost-effective and dependable hybrid battery replacements that offer a budget-friendly alternative to dealership prices—all while maintaining our commitment to exceptional quality.

    We understand that a failing battery can be an inconvenience. To make the process as seamless as possible, our professional mobile installation team can come directly to your home or workplace, bringing our specialist expertise to your doorstep. With a range of options designed to suit various budgets, Greentec Auto ensures that keeping your hybrid on the road remains accessible and affordable.

    FIND MY BATTERY

    CUSTOMER FEEDBACK

    Trusted by Hybrid & EV Owners Nationwide

    Found them through internet search. Requested mobile installation. They called back within 2 hours to set up an appointment. Turns out they had a shop near me, which saved me 50% on installation cost. Took about an hour.

    Prompt, quick, professional service. So much cheaper than getting another car. I would highly recommend their service to anyone who needs a hybrid battery replacement.

    Chris Walker (US)
    January 2, 2025

    I was so grateful that my friend told me about this company. What I thought was going to be a $8,500.00 repair, as quoted to me by my regular auto shop, turned into a $2,400.00 repair. I will be forever grateful to Greentec EV & Hybrid Batteries. Thank you guys so much. Their customer service was excellent over the phone, and my experience with the technician that came to my home to do the repair was also excellent. I can’t thank you all enough. You really saved me!!

    Lisa Tufano (US)
    January 10, 2025

    The hybrid battery on my Prius started dying and I managed to drive to the shop so I left it with them and told me they’ll finish it by tomorrow at 11am but they done it a lot earlier and faster than I expected. The car was running great again with the purchased of 12 month warranty remanufactured. I’m highly satisfied with the work they’ve done and I recommended them big time.

    Ellrick Garcia (US)
    February 13, 2025

    Frequently Asked Questions

    Hybrid and EV fault codes—technically known as Diagnostic Trouble Codes (DTCs)—are alerts generated by your vehicle’s on-board computer. They highlight specific irregularities within the powertrain, battery pack, or electrical systems. These codes allow technicians to pinpoint issues such as:
    • High-voltage battery degradation
    • Inverter or converter malfunctions
    • Charging system faults
    • Regenerative braking inefficiencies

    Common codes include:
    • P0A80: Replace Hybrid Battery Pack
    • P0A7F: Hybrid Battery Pack Deterioration
    • P0AC0: Hybrid Battery Pack Current Sensor Circuit Low
    If your dashboard displays a warning light, we recommend using an OBD2 reader to identify the specific code or consulting a specialist.
    There are several tell-tale signs that your high-voltage battery may be reaching the end of its lifespan:
    • Reduced Fuel Efficiency: You may notice the petrol or combustion engine engaging more frequently to compensate for the lack of electric power.
    • Warning Lights: Dashboard alerts or specific error codes (such as P0A80) usually indicate a system fault.
    • Difficulty Starting: A deteriorating battery may struggle to hold a sufficient charge, leading to ignition issues.
    • Performance Drop: You might experience a lack of power during acceleration or find that the vehicle struggles to stay in EV mode.
    • Audible Fan Noise: If the battery cooling fan is running loudly or constantly, it may be trying to cool overheating cells.
    If you suspect an issue, we recommend booking a diagnostic check to confirm the battery’s health.
    We strongly advise against driving if your vehicle is displaying a significant hybrid error code, particularly P0A80 (Replace Hybrid Battery). Continuing to drive with these faults can lead to:
    • Significant loss of power
    • Increased fuel consumption
    • Potential strain on the inverter or combustion engine
    In some cases, the vehicle may enter “limp-home mode,” severely restricting speed to protect the drivetrain. To avoid causing secondary damage to other components, it is best to have the vehicle inspected immediately.

    Yes, Greentec Auto offers a complimentary initial diagnostic service for hybrid system faults. If your dashboard is showing a “Check Hybrid System” warning or you have retrieved a specific fault code, our specialists can scan your vehicle to provide an accurate assessment of the issue without an initial fee.
